Pneumatic diaphragm pumps
Air-operated double diaphragm pumps are self-priming, dry-running proof positive displacement pumps. The diaphragms are connected by a shaft. The incoming compressed air sets the diaphragms in motion, which displaces volume.
While the medium is being pressurized in one chamber (pressure stroke), the medium flows into the other chamber (suction stroke), and then, due to the alternating movement of the shaft, it is transferred to the pressure chamber.
Air-operated diaphragm pumps (pneumatic diaphragm pumps) are found in all industries due to their simplicity, low purchase price and long service life.
Especially in ATEX (explosion-proof) areas, pneumatic diaphragm pumps are very often the ideal solution.
Available connections: 1/4" - 3/8" - 1/2" - 3/4" - 1" - 1 1/4" - 1 1/2", 2", 3"
Material selection:
- favorable purchase price
- pneumatic diaphragm pumps can handle everything from low to high viscosity media, even with high solids content
- can be used up to 20,000 mPas
- due to the wide range of materials and compact design, pneumatic diaphragm pumps can be used in almost all areas
- diaphragm pumps can also be used in ATEX areas
- dry running guaranteed
- self-priming up to 8 meters
- variable delivery capacity: adjustable from zero to maximum delivery capacity by changing the air flow
- no lubrication required
- few wearing parts and low maintenance requirements
